Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use

Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use
Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use

Image Grand :  Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use

Détails sur le produit:
Lieu d'origine: Chine
Nom de marque: GNEE
Certification: SGS
Conditions de paiement et expédition:
Quantité de commande min: ≥ 1 sept
Prix: According to the product
Conditions de paiement: LC, D/A, D/P, T/T, Western Union, MoneyGram
Capacité d'approvisionnement: 25 chaque mois
Contact

Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use

description de
Mettre en évidence:

Intelligent Control VPSA Oxygen Generator

,

Modular Design Oxygen Production Equipment

,

Long Service Life PSA Oxygen Generator

90-95% High Purity VPSA/PSA Oxygen Generators Medical Gas Oxygen Generator
VPSA Oxygen Producing Machine
The pressure swing adsorption (VPSA) oxygen production device operates under normal temperature conditions. It uses molecular sieves to selectively adsorb nitrogen from the air, reduces the pressure in the adsorption tower to desorb the nitrogen adsorbed in the molecular sieves, thereby achieving an adsorption-desorption cycle operation and continuously producing oxygen with a purity of 90-95%.
Technical Parameters
Oxygen Output (Nm3/h) Purity (%) Instrument Air Consumption (M3/h) Water Consumption (M3/h) Power Consumption (KW) Total Power (KW) Bed Layer Type Area (M3)
509010332.540vertical6 x 9
15090-9320156585vertical9 x 9
20090-93251586110vertical9 x 9
30090-933030132155vertical14 x 12
40090-934030172205vertical15 x 14
60090-935045258320vertical12 x 18
80090-936050344410vertical15 x 18
100090-936560436550vertical16 x 18
150090-939090675845vertical/horizontal18 x 18
200090-931001509001060vertical/horizontal18 x 24
Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use 0 Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use 1 Intelligent Control VPSA Oxygen Generator with Modular Design and Long Service Life for Industrial Use 2
Technical Features
  • Based on the principle of pressure swing adsorption, mature and reliable technology
  • Intelligent soft cycle switching with adjustable purity and flow rate
  • Reasonable system component configuration with low failure rate
  • Uniform airflow distribution reduces high-speed airflow impact
  • Perfect process design for optimal usage effect
  • Unique molecular sieve protection extends service life
  • Intelligent chain for unqualified oxygen exhaust ensures product quality
  • Optional automatic adjustment systems for flow rate and purity
  • Easy operation with stable performance and high automation capability
Working Principle
The system uses high-quality carbon molecular sieves as adsorbents. Under pressure, the different diffusion rates of oxygen and nitrogen molecules on carbon molecular sieves enables oxygen-nitrogen separation. The pressure variation allows for continuous adsorption and desorption cycles.
Using a two-tower process, one tower adsorbs and produces nitrogen while the other desorbs and regenerates, enabling continuous high-quality nitrogen production.
In addition to VPSA Oxygen Generators, we also produce PSA Oxygen Generators, storage tanks, heat exchangers and other products. For inquiries about VPSA Oxygen Systems or other products, please contact us at info@gneeheatex.com. We will be happy to assist you.

Produit Tag:

La valeur de l'oxygène de l'installation VPSA est de 300 Nm3/h.,

générateur d'oxygène VPSA industriel,

Installation d'oxygène à commande PLC
